Physical Specification

•  Gross Dimension (Indoor, WxHxD) : 1035x295x385 mm
• Gross Dimension (Outdoor, WxHxD) : 900x348x625 mm

• Net Dimension (Indoor, WxHxD) : 957x213x302 mm
• Net Dimension (Outdoor, WxHxD) : 770x300x555 mm
• Gross Weight (Indoor, kg) : 15.10 kg
• Gross Weight (Outdoor, kg) : 40.50 kg
• Net Weight (Indoor, kg) : 11.60 kg
• Net Weight (Outdoor, kg) : 37.80 kg
• Loading Quantity (20/40/40Hft without Pipe) : 86/180/208

Technical Information

• Piping Length (Max, m) : 25 m
• Piping Height (Max, m) : 10 m
• SVC Valve (Liquid (ODxL)) : 6.35
• SVC Valve (Gas (ODxL)) : 12.7
• Moisture Removal (l/hr) : 1.8 l/hr
• Air Circulation (Cooling, ㎥/min) : 13.20 ㎥/min
• Refrigerant (Type) : R32
• Low Ambient (Cooling, ℃) : 18~43 ℃
• Outdoor Unit (Compressor Type) : ROTARY

Air Flow

• Air Direction Control (Up/Down) : Auto
• Air Direction Control (Left/Right) : Manual
• Air Flow Control Step (Cool/Fan) : 3 / 3

Convenience

• Indoor Temp. Display : Yes
• Display On/Off : Yes
• Beep On/Off : Yes
• 24-Hour Timer : Yes
• Auto Restart : Yes

Operating Mode

• Auto Mode : Yes
• Fast Cool : Yes
• Good Sleep : Yes
• Dehumidification : Yes
• Fan Mode : Yes

Smart

• WiFi Embedded : No

- Dear value customer before make the order please read and agree to the standard installation term & conditions. Installation and commissioning indoor and outdoor unit air conditioners with standard accessory.

- The standard air condition :

• come with installation of indoor unit
• Installation of outdoor unit with bracket
• With 10 feet cooper pipping with insulation for inverter & non-inverter
• with 10 feet PVC drainage pipe

- Our standard installation including the 10 feet copper hose and 10 feet wire from the indoor unit to outdoor unit of the aircond set, normally 10 feet copper hose and 10 feet wire is more than enough for the normal installation. Besides, the aircond gas is included  as well

- Standard Installation not include dismatle old unit, power supply, wall hacking, concealed pipping and others not stated above

- For any additional jobs on side during installation, a separate quotation will be provided by Authorize Installer

Additional Charges Reference :

•  Extra Piping : RM 25 Per Feet
• Power Point : RM 150 / pcs
•  Additional charges will be applied if deliver to higher level without elevator
• Free setup doesn't include any extra wiring, water pipe, bracket and renovation works

- *For any additional jobs on side during installation, a separete quotation will be provided by Authorizer Installer

- If there is a old or defective item need to be dismantled first before install the new unit. We also have dismantling services and the charge is RM150, and we will help remove, throw the defective unit.

- Additional fees will be charged if the installation service includes:

• Extra work (eg. each floor staircase charge RM20)
• Rural area delivery
