Net Weight

• Indoor kg (lb) : 8 (18)
• Outdoor kg (lb) : 26 (57)

Refrigerant Pipe Diameter

• Liquid Side (mm) : ø 6.35
• Liquid Side (inch) : 1/4
• Gas Side (mm) : ø 9.52
• Gas Side (inch) : 3/8

Pipe Extension

• Chargeless Pipe Length (m) : 7.5
• Maximum Pipe Length (m) : 20
• Maximum Elevation Length (m) : 15
• Additional Refrigerant Gas* (g/m) : 10
• Power Supply : Indoor

Cleaner Air

• nanoeTMX : No
• nanoe-G : No
• Anti-Dust Coating : No
• Dust Sensor : No
• Odour-Removing Function : Yes
• Removable, Washable Panel : Yes

Comfort

• Radiant Cooling : No
• iAUTO-X : No
• iAUTO :No
• ECONAVI : No
• ECO Mode with A.I. : No
• Temperature Wave : No
• SLEEP : Yes
• Inverter Control : No
• Powerful Mode : Yes
• Quiet Mode : Yes
• Soft Dry Operation Mode : Yes
• Personal Airflow Creation : No
• Airflow Direction Control (Up Down) : Yes
• Manual Horizontal Airflow Direction Control : Yes

Convenience

• 24-Hour Dual ON OFF Real Setting Timer : No
• 24-Hour ON OFF Real Setting Timer : Yes
• LCD Wireless Remote Control : Yes
• Wireless LAN Remote Control For Internet Connection : No
• Wired Remote Control : Yes (Optional)

Reliability

• Random Auto Restart (32 Restart Patterns) : Yes
• Blue Fin Condenser : Yes
• Long Piping (Numbers indicate the maximum pipe length) : 20m
• Top-Panel Maintenance Access : Yes
• Self-Diagnostic Function : No

NOTE

• Please do not use copper pipes that are less than 0.6mm in thickness.
• *When pipes are not extended from the standard pipe length, the required amount of refrigerant is already in the unit.

- Dear value customer before make the order please read and agree to the standard installation term & conditions. Installation and commissioning indoor and outdoor unit air conditioners with standard accessory.

- The standard air condition :

• come with installation of indoor unit
• Installation of outdoor unit with bracket
• With 10 feet cooper pipping with insulation for inverter & non-inverter
• with 10 feet PVC drainage pipe

- Our standard installation including the 10 feet copper hose and 10 feet wire from the indoor unit to outdoor unit of the aircond set, normally 10 feet copper hose and 10 feet wire is more than enough for the normal installation. Besides, the aircond gas is included  as well

- Standard Installation not include dismatle old unit, power supply, wall hacking, concealed pipping and others not stated above

- For any additional jobs on side during installation, a separate quotation will be provided by Authorize Installer

Additional Charges Reference :

•  Extra Piping : RM 25 Per Feet
• Power Point : RM 150 / pcs
•  Additional charges will be applied if deliver to higher level without elevator
• Free setup doesn't include any extra wiring, water pipe, bracket and renovation works

- *For any additional jobs on side during installation, a separete quotation will be provided by Authorizer Installer

- If there is a old or defective item need to be dismantled first before install the new unit. We also have dismantling services and the charge is RM150, and we will help remove, throw the defective unit.

- Additional fees will be charged if the installation service includes:

• Extra work (eg. each floor staircase charge RM20)
• Rural area delivery
